Pro Serve
Healthcare Meal Delivery System

P1G

3 Zone Oven, with a Neo-Ceram Hot Top and Gantry

Cook & Serve
Purpose-built for cooking, regenerating, and serving fresh, chilled, or frozen bulk food, this unit gives customers the flexibility to choose their meal at the point of service. It’s ideal for multi-food portioning and distribution, featuring two completely independent ovens with unique multi-fan air re-circulation system allowing fast and even heat distribution throughout. Optimized for GN (Gastronorm) containers, there are eight shelf position in the oven set at 71 mm intervals . This allows up to eight GN 1/1 containers.

Moffat’s pioneering three-zone, multi-heat control system, provides precise management of food temperature, texture, and presentation. It also uses a unique multi-fan air recirculation system to deliver rapid, even heat distribution throughout. A stylish, black ceramic illuminated hot-top offers a self-regulating surface ideal for serving hot meals. Built for durability and hygiene, the unit features a bright polished stainless steel interior, satin-finished exterior panels, and plastic-coated front and sides. Heavy-duty hinged doors with robust slam-shut catches ensure long-lasting performance in demanding environments.

DOWNLOADS

Specification

Key features

LED display lighting and coloured LED oven mode indication (flash red when oven door is left open)
Food probe and HACCP data gathering system.
1/1 GN compatible. Simple to transfer to serving area or load from a companion trolley.
Neo-Ceram, thermo-panel hot top. (Self regulates around 95°C)
Steam automatic evac system & oven door air curtain.
Touch screen, total control system with multi function display and program choice.
3 fully controllable oven zones in a landscape configuration.
Multi fans deliver even heating across the entire oven chamber, ensuring consistent cooking results.
Designed for bulk production, with 8 shelf capacity in the oven (shelf pitch is 71mm)
Wide choice of coloured front & end panels. (Standard colour is Goose Wing Grey)
4 x precision castors, 2 swivel with brakes and 2 fixed. (Easy to push in a straight line)
Shelving and supports are removable for easy cleaning.
Hi-Tech insulation.
Cool to touch door with fully adjustable heavy duty hinges and a slam catch maintaining a tight seal.

Operating Modes

Cook & Serve - Use in the same manner as a traditional convection oven
Cook Chilled - Regeneration of chilled bulk food [0°C to 8°C optimum 5°C] to above 82°C
Cook Frozen - Regeneration of frozen bulk food [-6°C to -25°C optimum -18°C] to above 82°C
Keep Hot - Holding hot bulk food above 63°C, compartment controlled at 90°C
Serve Hot - Hot-top serving area controlled at 95°
