Six-S Space Saving Stainless Steel Shelving System

6S6/9/12/15/18PL
6S6/9/12/15/18PLSS
6S6/9/12/15/18PF
6S6/9/12/15/18PFSS
6S6/9/12/15/18PLH
6S6/9/12/15/18PLSSH
6S6/9/12/15/18PFH
6S6/9/12/15/18PFSSH

Designed for use in cold or dry stores, these extendable units will suit all types of application including restaurants, hospitals, warehouses, butcheries and bakeries.

Uprights are made from 30mm square section stainless steel with adjustable feet to compensate for uneven surfaces. Shelves are manufactured in stainless steel with a 50mm downturn and 15mm return all round in a satin smooth polish finish and are available in plain or perforated styles.

Our unique ‘Versiclamp’ system holds the shelves securely in place but allows for infinite adjustment to the distance between shelves. These shelving systems are available in 1500mm or 1800mm high units. These units can be supplied fully assembled or as a flat pack budget option with tools and instructions.



DOWNLOADS

Specification

Key features

  • Recommended Max Capacity per shelf
    600 Length 60kg, 900 Length 55kg,
    1200 Length 50kg, 1500 Length 45kg,
    1800 Length 40kg
  • Solid Shelf System 1500mm high
    Stainless steel Grade 430
  • Model Dimensions
    L x D x H
    6S6PL 600 x 520 x 1500
    6S9PL 900 x 520 x 1500
    6S12PL 1200 x 520 x 1500
    6S15PL 1500 x 520 x 1500
    6S18PL 1800 x 520 x 1500
  • Solid Shelf System 1500mm high
    Stainless steel Grade 304
  • Model Dimensions
    L x D x H
    6S6PLSS 600 x 520 x 1500
    6S9PLSS 900 x 520 x 1500
    6S12PLSS 1200 x 520 x 1500
    6S15PLSS 1500 x 520 x 1500
    6S18PLSS 1800 x 520 x 1500
  • Perforated Shelf System 1500mm high
    Stainless steel Grade 430
  • Model Dimensions
    L x D x H
    6S6PF 600 x 520 x 1500
    6S9PF 900 x 520 x 1500
    6S12PF 1200 x 520 x 1500
    6S15PF 1500 x 520 x 1500
    6S18PF 1800 x 520 x 1500
  • Perforated Shelf System 1500mm high
    Stainless steel Grade 304
  • Model Dimensions
    L x D x H
    6S6PFSS 600 x 520 x 1500
    6S9PFSS 900 x 520 x 1500
    6S12PFSS 1200 x 520 x 1500
    6S15PFSS 1500 x 520 x 1500
    6S18PFSS 1800 x 520 x 1500
  • Solid Shelf System 1800mm high
    Stainless steel Grade 430
  • Model Dimensions
    L x D x H
    6S6PLH 600 x 520 x 1800
    6S9PLH 900 x 520 x 1800
    6S12PLH 1200 x 520 x 1800
    6S15PLH 1500 x 520 x 1800
    6S18PLH 1800 x 520 x 1800
  • Solid Shelf System 1800mm high
    Stainless steel Grade 304
  • Model Dimensions
    L x D x H
    6S6PLSSH 600 x 520 x 1800
    6S9PLSSH 900 x 520 x 1800
    6S12PLSSH 1200 x 520 x 1800
    6S15PLSSH 1500 x 520 x 1800
    6S18PLSSH 1800 x 520 x 1800
  • Perforated Shelf System 1800mm high
    Stainless steel Grade 430
  • Model Dimensions
    L x D x H
    6S6PFH 600 x 520 x 1800
    6S9PFH 900 x 520 x 1800
    6S12PFH 1200 x 520 x 1800
    6S15PFH 1500 x 520 x 1800
    6S18PFH 1800 x 520 x 1800
  • Perforated Shelf System 1800mm high
    Stainless steel Grade 304
  • Model Dimensions
    L x D x H
    6S6PFSSH 600 x 520 x 1800
    6S9PFSSH 900 x 520 x 1800
    6S12PFSSH 1200 x 520 x 1800
    6S15PFSSH 1500 x 520 x 1800
    6S18PFSSH 1800 x 520 x 1800

Options

  • PGF Set of 4, all swivel castors, 125mm dia, two with brakes.
