BQ60/90C

The E&R Moffat Chillogen Banquet Trolley is the efficient, safe and stress-free solution to the problems of catering for banquets or special functions, big or small. These robust Banqueting trolleys provide a large capacity, mobile, chilled food regeneration solution for plated meals. Available in two models 60 or 90, Ideal for hotels, conferences, and event catering on a large scale. making it possible for a single unit to cater for events with up to 60 or 90 covers using 10’’ plates from a modest kitchen and provide food that tastes like it’s been freshly cooked on the day. Simply load it with your chilled plated meals and hold chilled until a pre-determined time then switch to regen mode manually or automatically. This Chillogen system turns the fridge compartment into a re-gen oven. No need to manually handle meals form one unit into another. The food is then regenerated to a suitable temperature and automatically can hold warm until ready to serve. Simply transfer the unit to the dining area and serve. Multi fan technology allows the plated covered meals to be regenerated and held in perfect condition.

These powerfully regen models use a unique power sharing function this allows each model to use two 13amp type power supplies.

It takes all the hassle out of the planning and organisation. There will be no more last-minute rush, no more delays and no worries about irate guests. Even if the guests are late the food will still be at the correct serving temperature.

CHILLOGEN BANQUET (5 in 1) MODEL
1 - It’s a rapid chiller, 2 – It’s a refrigerator, 3 – It’s a regeneration oven, 4 – It’s a conveyance trolley, 5 – It’s a hot cupboard ..Its a Chillogen Low investment high sustainability, no investment in blast chilling units, no Investment in refrigeration Cabinets, no investment in combination ovens, no investment in hot holding cabinets, no investment in hot conveyance Trolleys.

DOWNLOADS

Specification

Key features

Doors open 180º (on the 90 Model)
270º (on the 60 Model).
Internal rack with anti-tilt grid shelves.
Increased reliability. Should one element or fan fail the others will compensate and continue operating.
Fitted with a humidifier for choice of moist or dry air.
4 x 150mm diameter precision bearing
castors. 2x fixed and 2x swivel braked.
It is recommended that plate covers are used for enhanced food presentation and moisture retention. Special stackable Moffat robust stainless steel plate covers are available as an optional extra.Standard plate covers sizes are 230mm [9 inch plate], 255mm [10 inch plate], 280mm [11 inch plate], Bespoke plate covers are available on request.
BQ60C

Plate size	Covers
10" (255mm dia)	60
11" (280mm dia)	45
12" (305mm dia)	30

Note: covers are not stacked and are placed on 15 shelves

BQ90C

Plate size	Covers
10" (255mm dia)	90
11" (280mm dia)	75
12" (305mm dia)	60
13" (330mm dia)	60

Note: covers are not stacked and are placed on 15 shelves

Operating Modes

Rapid chill, hold chilled, reheat food, hold hot, transport food.
An optional transfer system increases convenience and flexibility even further.
The internal rack can be rolled out of the compartment onto a transfer dolly.
This allows food to be prepared and loaded at a satellite station.
With a spare internal rack and grid shelves, food can be prepared for the next operation while the trolley is in use.
